Product Details
· Hydraulically angles 30 degrees in either direction
· Replaceable bolt-on wear edge; optional rubber edge
· Skid shoes with adjustable height
· Spring-loaded trip mechanism
· Plow through the deepest drifts and push large piles of snow
· Fingertip controls make it easy to configure the hydraulically operated blade
· Standard, high-carbon steel cutting edge
· Trip moldboard reduces potential impact damage from obstructions
· The moldboard angles as much as 30 degrees right or left up to 30 degrees for protection. Standard snow blades feature a trip moldboard and heavy-duty snow blades feature a trip edge.
· The long-lasting depth shoes are adjustable to match your conditions.
· A high-carbon steel cutting edge is standard on the snow blade. Rubber and polyurethane edges also are available.
· Remove light or moderate snow from sidewalks, driveways and parking lots
· Fingertip controls make it easy to configure the hydraulically operated blade, tackling any snow removal job on the go. With the standard, high-carbon steel cutting edge。
SPECIFICATIONS / OPTIONS
Model | 020860I | 020872I | 020884I | 020896I |
Overall Width (mm) | 1575 | 1830 | 2130 | 2430 |
Overall Length (mm) | 1010 | 1010 | 1010 | 1010 |
Transport Height (mm) | 635 | 635 | 635 | 635 |
Overall Height (mm) | 978 | 978 | 978 | 978 |
Operating Width when rotated to Angle 30° (mm) | 1300 | 1580 | 1845 | 2100 |
Deflection angle(F)° | ±30 | ±30 | ±30 | ±30 |
Working Speed (Km/h) | 3~60 | 3~60 | 3~60 | 3~60 |
Weight(Kg) | 280 | 295 | 312 | 325 |
Against-Obstacle Height (mm) | ≤80 | ≤80 | ≤80 | ≤80 |
Working Pressure(mpa) | 14-21 | 14-21 | 14-21 | 14-21 |
