Heavy Duty Four In One Bucket
Hot Products
· This four-in-one attachment can be used as a bucket for loading, carrying and dumping; as a grapple for handling odd-shaped objects; or for dozing, leveling and spreading material with the clamshell open.
· Compact Wheel Loaders
· Designed to capitalize on the full capabilities of your compact wheel loader, this four-in-one attachment can be used as a bucket for digging, loading, carrying and dumping; as a grapple for handling odd-shaped objects; or for dozing, leveling and spreading material with an open clamshell.
· Replace the cutting edges on the rear of the clamshell and dozer
· The bottom of the bucket and clamshell are reinforced to improve strength and rigidity.
· The interlocking and serrated grapple edges hold objects securely, even heavy and odd-shaped materials.
· The bolt-on cutting edges protect the corners of the bucket. The combination bucket is built with heavy-duty cutting edges for long life.
· The bucket features interlocking, serrated grapple edges for clamping materials in a variety of applications, including construction, recycling and forestry.
· When the clamshell is fully opened, it can be used as a dozer blade.
· Composed of three wear steel plates and domestic high-end quality hydraulic cylinders.
Product Details
Model | Mini010440 | 010460 | 010472 | 010484 |
Overall length (mm) | 530 | 766 | 951 | 940 |
Overall Width (mm) | 1036 | 1586 | 2194 | 2195 |
Overall Height (mm) | 522 | 704 | 715 | 820 |
Open distance(mm) | 550 | 810 | 880 | 900 |
Weight(include hitch)(Kg) | 117 | 304 | 418 | 537 |
Flat container/loading capacity(m³) | 0.09/0.13 | 0.3/0.34 | 0.53/0.65 | 0.57/0.76 |
Working flow(L/min) | 10-15 | 20-30 | 20-30 | 20-30 |
Working pressure(MPa) | 21 | 21 | 21 | 21 |
Package volume (CBM) M3 | 0.98 | 1.5 | ||
Optional accessories | Standard auxiliary blade and side teeth, optional main teeth | |||
Suit to machine | Mini skid steer | Skid steer loader |
